CONTI^® Paint spray hose PA

Glues, Lacquers, Oils, Paints, Polar and aromatic solvents

PA, black, highly abrasion resisitant, non-porous, smooth

Synthetic fibres

NBR, grey, resistant to ozone, weather and UV

Length independently electrically conductive, R < 10² Ω

25 bar / 363 psi

from -25 °C / -13 °F up to +80 °C / +176 °F

nominal width	inner-Ø	wall thickness	length	working pressure	min. burst pressure	min. bending radius	weight
zoll/inch	mm	mm	m	bar/psi	bar/psi	aprx. mm	aprx. g/m
1/4	6	2.5	> 10	25/363	100/1,450	60	86
1/3	8	3.0	> 10	25/363	100/1,450	80	140
3/8	9	3.5	> 10	25/363	100/1,450	90	184
7/16	11	4.0	> 10	25/363	100/1,450	110	243
1/2	13	4.0	> 10	25/363	100/1,450	130	240

_{Pressure data relate to room temperature / High pressures and/or temperatures reduce the service life}
