PAGUCLAMP

The ideal half-shell fitting for the beverage and food industry

APPLICATIONS

Foodstuff industry, Milk processing industry, Other installations in the brewing, beverage and spirits industry

FURTHER PROPERTIES

1 set consisting of 2 half shells, 4 screws and 4 nuts, For hoses with helix, use a reduced nozzle!, Material: stainless steel, No damage to lining through swaging process, Optimally adapted to PAGUFIX® nozzles due to the coordinated tooth geometry, Reusable, Rubber protection rings available in blue, Smooth and hygienically clean connection, without any transition between lining and fitting, Very high compression strength and resistance to to pull-off forces, also with hot cleaning through ideal tooth geometry

WORKING PRESSURE UP TO

16 bar / 232 psi

nominal width	inner-Ø	wall thickness	length	working pressure	min. burst pressure	min. bending radius	weight
zoll/inch	mm	mm	m	bar/psi	bar/psi	aprx. mm	aprx. g/m
3/4	19	5.0		16/232	48/696		222
1	25	6.0		16/232	48/696		402
1 1/4	32	6.0		16/232	48/696		436
1 1/4	32	8.0		16/232	48/696		464
1 1/2	38	6.5		16/232	48/696		521
1 1/2	38	9.0		16/232	48/696		580
2	50	8.0		16/232	48/696		727
2	50	10.0		16/232	48/696		814
2 1/2	63	8.0		16/232	48/696		1,070
2 1/2	63	12.0		16/232	48/696		1,145
3	75	8.0		16/232	48/696		1,349
3	75	12.0		16/232	48/696		1,648
4	100	9.0		16/232	48/696		2,065
4	100	15.0		16/232	48/696		2,163

_{Pressure based on room temperature / High pressure and/or temperature lead to reduced component durability}
